Prolog

This page is under construction!

Attention

This page has been tested and developed with the Mozilla browser. This page requires JavaScript in your browser. Without JavaScript or JavaScript beeing disabled, the display of this side is incomplete.

Basic Definitions

The matrix basics can be found on the linear algebra page.

Permutation

In general a permutation is a rearrangement of elements of an ordered list like the elements of a vector. Permutations can be expressed as matrix operations on a vector. If an arrangement contains n elements n! different permutations are possible.

Permutaions as Matrix Operations

A permutation is a matrix operation that leads two the exchange of the elements of a vector, when the matrix is multiplied with the vector.

The unit matrix is a permutation matrix, that leaves the order of the vector elements unchanged when applied to the vector.

Exchange Matrix

The exchange Matrix is the next example of a permutation matrix.

The exchange matrix or counterbrace matrix Jn, is a matrix where the counterdiagonal elements are all one. All other elements are zero.

The product of the exchage matrix with a column vector will result in a reordering of the column elements. The product of a row vector with a exchange matrix will result in a reordering of the row elements.

Square of the Exchange Matrix

J2 = I

The square of the exchange matrix is the unit matrix. Applying the exchange matrix twice will result in the original matrix.

Transpositions

Transpositions are permutations where only two rows of a matrix are exchanged. Every permutation can be expressed as a product of transposions.

Transpositions with a 2*2 matrix:

With two elements 2! = 2 permutations are possible.

Transpositions with a 3*3 matrix

With three elements 3! = 6 permutations are possible.

Factorisation of a Matrix A in Triangular Matrices A=LU

U is a upper triangular matrix and L is a lower triangular matrix:

Elimination Matrix

With the elemintion matrix E21 it is possible to bring a 2×2 matrix A into the upper triangular form U.

Example

A=(E21)-1U = LU

(E21)-1 is the lower triangular matrix L.

Nilpotent Matrices

Matrix A is called nilpotent of grade n when An=0.

Example 3x3 Matrices

Example 4x4 Matrices

Schloss Waldeck
Bild: "Schloss Waldeck"

The next page is about rotation matrices.
